1.3.2 Stationary control
The Tryton 112 bar-feeder is equipped
with a stationary control which is very
useful when conducting mechanical
adjustments to the feeder.
This control is active only in manual
mode. As soon as the feeder is in
automatic mode, the stationary control
becomes inactive.
The stationary control makes the following movements possible :
C Advance and retract connector : regulating the clamping jaws
C Advance and retract pusher : regulating the end of bar
changing the collet
C Indexing the barrel : replenishing the barrel
changing the working diameter (Hybrid)
