5 - 2 CHAPTER 5 : PNEUMATICS
TRYTON 112 CNC
1. PNEUMATIC EQUIPMENT
Please read the safety precautions described at the beginning of this manual
before handling the following devices.
1.1 Description
The following movements of the Tryton 112 bar-feeder are effected by pneumatic elements:
C Locking the barrel
C Front positioning end-stop
C Engaging the cable-feed device
C Opening the outboard support (optional)
To guarantee an optimal operation of the bar feed system, a minimum pressure of 5 bar
(75 PSI), and a maximum pressure of 6 bar (90 PSI) is mandatory.
