CHAPITRE 2 : CHAPTER 2: TECHNICAL DATA 2 - 3
TRYTON 112 CNC
2. FLOOR PLAN
The following floor space plan indicate the most frequently used dimensions for placing
the bar feed system. Details on the dimensions of other parts or elements of the bar feed
system will be furnished upon request.
The plan shows a feeder with right-hand loading (B). The measurements of feeders with
left-hand loading (A) are the same. The views are merely reversed.
All measurements are in millimetres.
