9 - 6 CHAPTER 9 : MALFUNCTIONS
TRYTON 112 CNC
2.3 Battery
In the event of a power failure, a backup battery saves the data contained in the PLC.
It is possible that with time this battery will slowly drain; in this case a message will be
displayed on the remote control.
Recommended battery use :
Use of automaton
Temperature : 25/C
Temperature : 55/C
100% off
3 years 6 months
100% on
5 years
4 years
30% off 70% on
4 years 1 year
The battery must be replaced as soon as possible with a battery of the same type :
CD0032 / 3V LITHIUM
Procedure :
Particular attention must be paid when manipulating electric components
because there is a risk of electrocution.
• Bar-feeder on
• Open electric cabinet
• Open lid of the module by pulling
it forward.
• Replace battery
• Close module again
• Close cabinet again
