6. Function Description
6-50
6.4.13 Brake opening and closing setting
1) FUN_65(Brake opening time)
2) FUN_66(Brake opening speed)
3) FUN_67(Brake opening current)
4) FUN_68(Brake closing time)
5) FUN_69(Brake closing speed)
z
It only operates when multi-aux ouput terminal(DIO_41 ~ DIO_43)is set to Brake Output.
The motor brake is not opened during motor’ Auto-tuning, so be sure to open the brake forcedly when
you do the rotating type motor’s Auto tuning.
z
About Brake opening time, Multi-aux output terminal becomes on after passing initial excitation time of
motor and it operates with the brake opening speed during set time.
z
About Brake opening speed, Multi-aux output terminal becomes on after passing initial excitation time
of motor and it operates with the set speed during brake opening time.
z
Brake openig current value is set as the percentage of magnetic current of motor. The brake openig
signal operates only after ocurring more output current than set value.
z
Brake closing time means the set time after multi-aux output terminal is off below the brake closing
speed. Set more high brake closing time value than decelerating time between brake closing speed and
0.
z
At the brake closing speed, multi-aux ouput teminal becomes off.
z
If Backlash phenomenon occurs when the motor is stopping, increase the brake closing set value more
and more until the Backlash phenomenon isn’t occurs anymore. At the same time, adjust also the brake
closing time set value.
Code Display Description Range Unit Default
FUN_65 BKOpen Time Brake opening time 0.00 ~ 30.00 sec 0.00
FUN_66 BKOpen Spd Brake opening speed 0.0 ~ 500.0 rpm 0.0
FUN_67 Release Curr Brake opening current 0.0 ~ 150.0 % 20.0
FUN_68 BKClose Time Brake closing time 0.00 ~ 30.00 sec 0.00
FUN_69 BKClose Spd Brake closing speed 0.0 ~ 500.0 rpm 0.0
