LS Industrial Systems SV-iV5 Series User Manual

7. WEB Control Application
7-14
2) Multi-function Auxiliary Output Terminal Definition (DIO_41 AX1 Define ~ I/O_43 OC1 Define)
When CON_02 Application of Control (CON) Group is selected as “WEB Control”, you can select the following
function in addition. For further detail, please refer to WEB group function explanation.
Definition of Function
Functio
nCode
Loader
Display
Name Setting Range
Unit Explanation of Function
Web Break
Detection
WEB Break % Detects and outputs the short of Web
Up to Speed
Detection
Up to Spd %
Detects and outputs the deviation between
line speed command and actual line speed
DIO_41 AX1 Define
False Core
Detection
False Core %
Outputs if the diameter is less than the set
value in WEB_16
The rest of the multi-function output terminal has the same function. In the standard input/output board, however,
AX1 and AX2 are relay output while OC1 is open collector output.
7.5.3 Analog Input/Output Group (AIO_[][])
If you select “WEB Control” at CON_02 Application, you can select following functions more. The function
description is simple, so refer to WEB Group function description for more details.
Definition of Function
Function
Code
Loader
Display
Name Setting Range
Unit Explanation of Function
Line Speed Command Line SPD Ref %
The set value of WEB_08 MaxMotor SPD is
maximum line speed command 0 ~ 100% where
the input is 0 ~ 10V. In case of ±10V input, it
recognizes 0 ~ 10V.
Tension Command Tension Ref %
I
t means the maximum tension command value is ± 10 where the inpu
t
Dancer Position
Command
Dancer Ref %
It means dancer command value is ±100% where
the input is ±10V
Taper Command Taper Ref %
It means taper command value is ±100% where
the input is ±10V
Tension Feedback Tension F/B %
It means the amount of tension feedback is
±100% where the input is ±10V
Diameter Input Diameter %
In case of using the diameter sensor, it means
the diameter is ±100% where the input is ±10V
AIO_01 Ai1 Define
Diameter Initialization Diam Preset %
In case of using diameter initialization
by analog
input, it means the diameter is ±100% where the
input is ±10V
Final Line Speed
Command
Line Speed %
Outputs the final line speed command that is the
sum of line speed command and PID controller
output
Final Tension
Command
Tension Out %
Outputs the final tension command after
computing Taper, Boost, and Stall
AIO_74
AO1
Define
Diameter Diameter % Outputs the current diameter
