Chapter 2 - Specification
2.1 Standard Specification
2.1.1 200V Class (AC power input type)
SV[][][]iV5-2(DB) 022 037 055 075 110 150 185 220 300 370
[HP] 3 5 7.5 10 15 20 25 30 40 50
Max. applicable
motor output
Note1)
[kW] 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37
Capacity [kVA]
(Note2)
4.5 6.1 9.1 12.2 17.5 22.5 28.2 33.1 46 55
Rated current [A] 12 16 24 32 46 59 74 88 122 146
Speed 0 ~ 3600(rpm)
Output
Voltage 200 ~ 230V
(Note3)
Voltage
3φ 200 ~ 230V(-10% ~ +10%)
Input
Frequency
50 ~ 60Hz(±5%)
Inverter weight [kg(lbs)]
6
(13)
6
(13)
14
(30)
14
(30)
27.5
(60)
27.5
(60)
28
(61)
28
(61)
42
(93)
42
(93)
2.1.2
400V Class (AC power input type)
SV[][][]iV5-4(DB) 022 037 055 075 110 150 185 220 300 370
[HP] 3 5 7.5 10 15 20 25 30 40 50
Max.
applicable
motor output
Note
1)
[kW] 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37
Capacity [kVA]
(Note2)
4.5 6.1 9.1 12.2 18.3 22.9 29.7 34.3 46 57
Rated current [A] 6 8 12 16 24 30 39 45 61 75
Speed 0 ~ 3600(rpm)
Output
Voltage 380 ~ 480V
(Note3)
Inverter weight [kg(lbs)]
6
(13)
6
(13)
14
(30)
14
(30)
27
(59)
28
(61)
28
(61)
28
(61)
42
(93)
42
(93)
SV[][][][]iV5-4(DB) 450 550 750 900 1100 1320 1600 2200 2800 3150 3750
[HP] 60 75 100 120 150 175 215 300 373 420 500
Max.
applicable
motor output
Note
1)
[kW] 45 55 75 90 110 132 160 220 280 315 375
Capacity [kVA]
(Note2)
70 85 116 140 170 200 250 329 416 468 557
Rated Current [A] 91 110 152 183 223 264 325 432 546 614 731
Speed 0 ~ 3600(rpm)
Output
Voltage 380 ~ 480V
(Note3)
Inverter weight [kg(lbs)]
63
(139)
63
(139)
68
(150)
98
(216)
98
(216)
122
(269)
122
(269)
175
(386)
243
(536)
380
(838)
380
(838)
Voltage
3φ 380 ~ 480V(-10% ~ +10%)
(Note4)
Input
Frequency
50 ~ 60 Hz (±5%)
※ The electrical specifications of the MD type (2.2~22kW Class) are the same as the above.
SV[][][]iV5-2/4DB(MD) 055 075 110 150 185 220
Inverter weight [kg(lbs)] 7.7(16.9) 7.7(16.9) 13.7(30.2) 13.7(30.2) 20.3(44.7) 20.3(44.7)
