6. Function Description
6-77
4) Time out for command loss of Multi-function analog input (AIO_73 Time out)
It means the time for judging the loss time of analog input. If the time that is set at AIO_73 Time Out is passed, it can
be considered as analog input loss
Definition
Code Display
Name
Setting
range
Unit Function description
AIO_73 Time out
T
ime for loss of
Multi-function analog
input
0.1 ~ 120.0 sec
It sets the time for judging command loss when
the analog input is keeping from the moment of
satisfying the condition set at multi-function
analog input loss criterion until the set time.
AIO_73 Time out can be applied 세 AIO_12 Ai1 Wbroken, AIO_24 Ai2 Wbroken, AIO_36 Ai3 Wbroken.
(In the case of I/O(EXTN_I/O, it can also be applied to AIO_48 Ai4 Wbroken, AIO_60 Ai5 Wbroken.)
6.8.3 Analog output
1) AIO_74 ~ 83(description for multi-function analog output terminal, output source , Bias, Gain,
setting absolute value)
SV-iV5 offers 2 analog outputs and according to the options of user, you can vary the description for using.
The output rage is -10V ~ +10V and the types are as follows.
Function Definition
Key Display
Name Range
Unit Function Description
AIO_74 AO1 Define
Multi-function analog
output A01 definition
It describes type of multi-function analog
output A01.
AIO_75 AO1 Source
Mullti-function analog
output A01 output
source definition.
-10 Æ 10V
10 Æ -10V
0 Æ 10V
10 Æ 0V
It describes source of multi-function analog
output A01.
AIO_76 AO1 Bias
Multi-function analog
output A01 Bias
-100.0 ~
AIO_77
%
. It describes Bias of multi-function analog
output A01.
AIO_77 AO1 Gain
Multi-function analog
output A01 Gain
0.0 ~
500.0
%
It describes Gain of multi-function analog
output A01.
AIO_78 AO1 ABS
Multi-function analog
output A01
the absolute value
setting
No / Yes
It is possible to have positive absolute value
of analog output A01.
