7. WEB Control Application
7-2
7.2 Loader Display in WEB Control Mode
7.2.1 Home Screen
The status of the screen as above is called “Home Screen of Display Group” or “Home Screen”, and you can
return to this home screen by pressing SHIFT/ESC key. Each item on the screen shows the associated information as
shown in the table below.
Item
No.
Title Function
1 Motor Speed Indicate actual rotating speed of the motor in rpm
2
Motor Control Mode
SPD : Speed Control Mode
TRQ : Torque Control Mode
WEB : WEB control mode
BX : Indication of Emergency Stop State
3 Detent Torque
Indicate detent torque occurred against 100% rating output of
the motor
4
Inverter Output
Current
Indicate effective value for the inverter’s actual output current
7. 3 change of Parameter Group
When selecting WEB control application mode WEB Control Group (WEB) is added following the user group.
Name of Group
LCD loader
(Left upper
corner of LCD)
Major Description
Display Group DIS
Motor Speed, Motor Control Mode, Detent Torque, Inverter Output Current,
User Selection Display, Process PID Output / Ref / Fdb, Current Failure
State,
User Group Display Setting
Digital I/O Group DIO Digital Input Parameter, Digital Output Parameter, etc.
Parameter Group PAR
Parameter Initialization, Parameter READ / WRITE / LOCK / PASSWORD,
Motor-related Constant, Auto-Tuning, etc.
Function Group FUN
Operation Frequency, Operation Method, Stop Method,
Acceleration/Deceleration Time and Pattern,
Carrier Frequency, Electronic Thermal Selection, etc.
Control Group CON
Control Mode, ASR PI Gain, Process PID Gain, Draw Control Setting,
Droop Control-Related Constant, Torque Control-Related Constant, etc.
External Group EXT Parameter Setting for Communication Option Mode, etc.
Analog I/O Group AIO Analog Input- Related Parameter, Analog Output Parameter, etc.
WEB group WEB
Diameter and tension control setting parameters, etc. at the time of Web
Control
z For further details by groups except WEB group, please refer to Function in Chapter 6 of the Main Manual.
0.0rpm WEB
Tq
0
.0% 0.0A
4
3
1
2
