6.1.3 DIS_04 (Process PID controller)
Information on Output, reference, F/B values of Process PID controller is displayed in this code.
6.1.4 DIS_05 (Fault display)
Current fault status, previous two faults, the number of faults occurred and faults information reset are available
using [SHIFT/ESC] key in DIS_05.
Code LCD display Parameter name Description
Faults
Current Trip
displayed
“-------” displayed when normal.
Trip information given when tripped.
Last Fault1 2
nd
fault displayed
Last Fault2 1
st
fault displayed
Refer to Chapter 8. Troubleshooting.
Fault Count
Total number of
faults
The number of total faults in memory from the initialization
until now is displayed.
DIS_05
Fault Clear Reset
Clear the faults and initialize to “0”.
Faults information, speed reference before fault occurs, speed F/B value, output frequency/ current/ Voltage, torque
current reference & actual value, DC Link voltage, input terminal status, output terminal status, Run status, running time
can be monitored using [PROG], [
▲
(Up)] / [
▼
(Down)] keys. Pressing [ENT] key will return to top. To enter the fault
info into memory as [Last Fault 1], press [RESET] key. Refer to [Chapter 9 troubleshooting and maintenance] for more
details.
Process PID output
Process PID F/B value
Process PID reference value
PIDOut 0.0%
* 0.0%
0.0%
