LS Industrial Systems SV-iV5 Series User Manual

7. WEB Control Application
7-12
7.5.2 Digital Input/Output Group (DIO_[][])
1) DIO_01 ~ DIO_07 (Definition of multi-function input P1~7)
In case of selecting CON_02 Application of Control(CON) Group as “WEB Control”, you may select the following
function in addition. For further detail, please refer to the explanation on WEB group function.
Functio
n Code
Loader Display Name of Function Unit
Dia Hold
Diameter Computation Hold
Command
Select when desiring to hole the diameter
computation
Dia Preset
Diameter Initialization
Command
Select when initializing diameter
CoreSize-L Core Select 1 Function
CoreSize-H Core Select 2 Function
Select one of WEB_04 ~ WEB_07 by On/Off of the
multi-function input terminal at the time of
diameter initialization by keypad
CoreSize-
L
CoreSize-
H
Preset Core
Applied
OFF OFF
WEB_04 Diam Preset
1
ON OFF
WEB_05 Diam Preset
2
OFF ON
WEB_06 Diam Preset
3
ON ON
WEB_07 Diam Preset
4
Tension Disable Tension Control Prohibition
Prohibit the process PID controller output when the
set multi-function input terminal is On.
PI Gain Sel
Process PID Controller PI Gain
Transfer
PI Gain of process PID is transferred from 1 to
2
when the set multi-function input terminal is On.
(WEB_30) (WEB_31) (WEB_32) (WEB_33)
PID ITerm Clear
Accumulated portion of I
controller of Process PID
controller is initialized
Accumulated portion of I controller of Process
PID controller is initialized
when the set multi-
function input terminal is On.
Taper Disable Taper Function Prohibition
Stops the taper function when the multi-
function input terminal set during operation
mode by taper function is On
Stall Enable Stall Function Setting
Stall function operates when the set multi-function
input terminal is On.
Boost Enable Boost Function Setting
Boost function operates when the set multi-
function input terminal is On
Quick Stop
Emergency Stop Function
Setting
Inverter stops after the lapse of the time set in
WEB_54 when the multi-function input terminal set
to stop the inverter operation at emergency is On
Jog Web Jog operation function Setting
Jog operates when the set multi-function input
terminal is On. FUN_01 should be set to
“Terminal 1”, and Jog operates even if Fx
terminal is not On
Under Wind Under wind function Setting
Although the value in WEB_18 is set to “Overwind”,
it operates Under wind if the set multi-function
input terminal is On.
DIO_01
~
DIO_07
Unwinder Unwinder function Setting
Although the value in WEB_17 set to “Rewind”, it
operates Unwinder if the set multi-function input
terminal is On.
