LS Industrial Systems SV-iV5 Series - 3.3 Power Circuit Terminal; 3.3.1 Power circuit terminal arrangement

3. Installation and Wiring
3-7
3.3 Power Circuit Terminal
3.3.1 Power circuit terminal arrangement
(1) AC power sorce input type
CAUTION
Be sure that “N” is not Neutral Line but DCN(-) and P is DCP(+)
 SV022, 037, 055, 075, 110, 150, 185, 220iV5-2(DB)
SV022, 037, 055, 075, 110, 150, 185, 220iV5-4(DB)
R S T
U V W G N(-) B2 B1 P(+)
 SV110, 150, 185, 220iV5-2(DB)(MD)
SV110, 150, 185, 220iV5-4(DB)(MD
) *(MD) : Mold Type
R S T
U V W N(-) B2 B1 P(+)
 SV300, 370iV5-2
SV300, 370, 450, 550, 750iV5-4
R S T
G U V
W
P1(+) P2(+) N(-)
 SV900, 1100, 1320, 1600, 2200iV5-4
R S T
G
U V W P1(+) P2(+) N(-)
 SV2800, 3150, 3750iV5-4
R(L1) S(L2) T(L3) P1(+) P2(+) N(-) G U V W
G
