7. WEB Control Application
7-22
computation is not conducted. If the line speed command is smaller than the set value, and the multi-function input
terminal set to “Dia Preset” is On, the diameter can be initialized. The reference of the set value is the [%] of
maximum line speed.
Function
Code
Loader Display Name of Function Set Range Unit
Factory
Default
WEB_09 MinLine SPD
Minimum Effective Line
Speed
0.0 ~ 100.0 % 5.0
3) WEB_10 Min Diameter : Minimum Diameter
It indicates the diameter of the smallest core [%], which is used as the minimum limit of diameter computation at
the time of Taper computation, P Gain Profiler computation, and Unwinder operation, the minimum limit in
diameter computation at the time of Unwinder operation, and the minimum limit in the diameter initialization using
analog communication, diameter initialization using communication, diameter computation using diameter sensor.
In the inverter S/W, if the set value of WEB_10 Min Diameter is larger than the set value of WEB_04 Diam Preset 1
~ WEB_07 Diam Preset 4, it is limited to the set value of WEB_10 Min Diameter. Therefore, the set value of
WEB_10 Min Diameter should be set to the set value equal to or less than that of WEB_04 Diam Preset 1 ~
WEB_07 Diam Preset 4. If applying Bridle Roll or Nip Roll other than general winder and unwinder, the set value of
WEB_10 Min Diameter should be set as 100[%].
Function
Code
Loader Display Name of Function Set Range Unit
Factory
Default
WEB_10 Min Diameter Minimum Diameter 5.0 ~ 100.0 % 10.0
4) WEB_11 AccDecWeb : Selecting Acceleration/Deceleration Time Setting at the time of Web Control
5) WEB_12 Acc TimeWeb : Acceleration Time at the time of Web Control
6) WEB_13 Dec TimeWeb : Deceleration Time at the time of Web Control
When setting WEB_11 AccDecWeb to “No”, WEB_12 Acc TimeWeb and WEB_13 Dec TimeWeb are not displayed
on Keypad, but acceleration/deceleration time of FUN_40 Acc Time-1, FUN_41 Dec Time-1is applied at the time of
Web control. When set to “Yes”, WEB_12 Acc TimeWeb and WEB_13 Dec TimeWeb are displayed on Keypad, and
then the set value of WEB_12 Acc TimeWeb and WEB_13 Dec TimeWeb are applied to the
acceleration/deceleration time, and the reference of acceleration/deceleration reference is “Max Speed”.
Function
Code
Loader Display Name of Function Set Range Unit
Factory
Default
WEB_11 AccDecWeb
Selecting
Acceleration/Deceleration
Time Setting at the time of
Web Control
No
Yes
Yes
WEB_12 Acc TimeWeb
Acceleration Time at the time
of Web Control
0.00 ~ 6000.0 sec 0.50
WEB_13 Dec TimeWeb
Deceleration Time at the
time of Web Control
0.00 ~ 6000.0 sec 0.50
7.7.5 Diameter Computation
1) WEB_14 Diameter Src : Diameter Computation Type Setting
