LS Industrial Systems SV-iV5 Series User Manual

2. Specification
2-2
2.1.3 400V Class (DC power input type)
SV[][][]iV5-4DC 055 075 110 150 185 220 300 370 450 550
[HP] 7.5 10 15 20 25 30 40 50 60 75
Max.
applicable
motor output
Note1)
[kW] 5.5 7.5 11 15 18.5 22 30 37 45 55
Capacity [kVA]
(Note2)
9.1 12.2 18.3 22.9 29.7 34.3 46 57 70 85
Rated Current [A]
12 16 24 30 39 45 61 75 91 110
Speed
0 ~ 3600(rpm)
Output
Voltage
380 ~ 480V
(주 3)
Input rated voltage
DC 540 ~ 680V(+10%)
(주 5)
Inverter weight [kg (lbs)]
12
(26)
12
(26)
24
(53)
24.5
(54)
25
(55)
25
(55)
38.5
(84)
38.5
(84)
50
(110)
50
(110)
SV[][][]iV5-4DC 750 900 1100 1320 1600 2200 2800 3150 3750
[HP] 100 120 150 175 215 300 373 420 500
Max.
applicable
motor output
Note1)
[kW] 75 90 110 132 160 220 280 315 375
Capacity [kVA]
Note2)
116 140 170 200 250 329 416 468 557
Rated Current [A]
152 183 223 264 325 432 546 614 731
Speed
0 ~ 3600(rpm)
Output
Voltage
380 ~ 480V
( note3)
Input rated voltage DC 540 ~ 680V(+10%)
note5)
Inverter weight [kg (lbs)]
55
(121)
79
(174)
79
(174)
98.5
(217)
98.5
(217)
154.5
(340)
206
(454)
343
(756)
343
(756)
Note)
1. It represents the output capacity of maximum applicable motor in case LG-OTIS 4- pole motor is used.
2. Rated capacity (=√3*V*I) is calculated based on 220V for 200V class, 440V for 400V class.
3. Maximum output voltage cannot be generated above specified input voltage.
4. Derate the rated current by 10% when the input voltage is in the range of 507 ~ 528V.
5. Rated current is derated by 10 % above 680 VDC of input voltage.
