LS Industrial Systems SV-iV5 Series User Manual

7. WEB Control Application
7-17
Setting Data
Code
No.
Comm.
Addr
Code Name LCD DISPLAY
Range Unit Default
Adjustment
During Run
PAGE
WEB_34 7C22
PID Gain Ramp Time
Setting
PIDGain RAMP 0.1 ~ 100.0 sec 1.0 Yes 7-32
WEB_35 7C23
Process PID P Gain Profiler
Type Setting
P Profiler
0 (Linear)
1 (Square)
2 (Cubed)
3 (Quadratic)
0 (Linear) No 7-32
WEB_36 7C24
Process PID P Gain Profiler
Gain Setting
P Apt Gain -1.00 ~ 10.00 0.00 No 7-32
WEB_37 7C25 Process PID D Gain Setting ProcPID Kd 0.0 ~ 100.0 % 0.0 Yes 7-33
WEB_38 7C26 Process PID D Gain LPF ProcKd LPF 0.0 ~ 100.0 sec 2.0 Yes 7-33
WEB_39 7C27 Process PID Positive Limit Proc Pos Lmt -100.0 ~ 100.0 % 100.0 Yes 7-33
WEB_40 7C28 Process PID Negative Limit Proc Neg Lmt -100.0 ~ 100.0 % -100.0 Yes 7-33
WEB_41 7C29
Process PID Output LPF
Time Constant
PID Out LPF 0.00 ~ 100.00 sec 1.00 Yes 7-34
WEB_42 7C2A
Rewind-Use Process PID
Output Gain
PIDOGainRe -250.0 ~ 250.0 % 0.0 Yes 7-34
WEB_43 7C2B
Unwind-Use Process PID
Output Gain
PIDOGainUn -250.0 ~ 250.0 % 0.0 Yes 7-34
WEB_44 7C2C PID Controller Type Setting PID Type
0 (Proportional)
1 (Fixed)
0 (Proportional) No 7-34
WEB_45 7C2D
Minimum PID Controller
Output Setting
Min FPID 0.0 ~ 50.0 % 10.0 No 7-34
WEB_46 7C2E
Time of Maintenance of PID
Controller After Break
PIDHoldTime 0.0 ~ 100.0 sec 5.0 Yes 7-36
WEB_47 7C2F
Process PID Feedback Type
Setting
PID F/B Src
0 (Analog)
1 (Option)
0 (Analog) No 7-36
WEB_48 7C30
WEB Break Detection
Function Setting
WB Enable 0 (No) / 1 (Yes) 0 (No) Yes 7-38
WEB_49 7C31
Setting of Time Delayed until
Web Break Detection after
Inverter Operation
INV WB Delay 0.1 ~ 600.0 sec 1.0 Yes 7-38
WEB_50 7C32
Time
Delayed for WEB Break
Detection
WB Delay 0.1 ~ 600.0 sec 1.0 Yes 7-38
WEB_51 7C33 WEB Break Detection Level WB Level 0.0 ~ 100.0 % 0.0 Yes 7-38
WEB_52 7C34
Up to Speed Judgment
Setting
UTS Enable 0 (No) / 1 (Yes) 0 (No) Yes 7-39
WEB_53 7C35 Up to Speed Level UTS Level 0.0 ~ 100.0 % 0.0 Yes 7-39
WEB_54 7C36 Quick Stop time Setting Quick Stop 0.0 ~ 100.0 sec 1.0 Yes 7-39
WEB_55 7C37 Jog Speed Setting JogSpd Web 0.0 ~ 100.0 % 10.0 Yes 7-40
WEB_56 7C38
Jog Acceleration/Deceleration
Time Setting Select
JogTime Sel 0 (No) / 1 (Yes) 1 (Yes) No 7-40
WEB_57 7C39 Jog Acceleration Time Setting JogAcc Time 0.00 ~ 6000.0 sec 5.00 Yes 7-40
WEB_58 7C3A Jog deceleration time Setting JogDec Time 0.00 ~ 6000.0 sec 5.00 Yes 7-40
WEB_59 7C3B Splicing Level Setting Splice Level 0.0 ~ 100.0 % 0.0 Yes 7-40

LS Industrial Systems SV-iV5 Series Specifications

General

Category	Inverter
Series	SV-iV5
Output Voltage	0-Input Voltage
Output Frequency	0.1-400Hz
Frequency Range	0.1-400Hz
Control Method	V/F control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground fault
Communication	RS485 (Modbus RTU)
Cooling Method	Fan Cooling
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5~95% RH (Non-condensing)
Altitude	Up to 1000m without derating
