5-24
Application Manual CDA3000
5 Software functions
Parameters for analog output
Settings for 200-FOSA0
Parameter Function Value range FS Unit Online
200-FOSA0 Function selector analog standard output
OSA00
see Table 5.14 ACTF
201-OAMN0 Minimum value for analog output OSA00 -200 ... 200 0 %
202-OAMX0 Maximum value for analog output OSA00 -200 ... 200 100 %
203-OAFI0 Filter time constant for analog channel OSA00
(2
x
), x = 0 ... 6
4
204-TSCL Torque scaling value *, see Table 5.15 * Nm
Table 5.13 Parameters from subject area _20OA Analog output
Explanatory notes
• For the two vertices (0 V, 10 V) the actual value can be adapted in
the range from - 200 % to + 200 % relative to a referenced value.
BUS KP/DM Function Effect/Notes Referenced value 10 V
0 OFF No function Output off
1 ACTF Current actual frequency Clockwise only (positive values only)
Control mode FOR: true actual frequency
Control mode SFC: estimated actual frequency
Open-loop control mode VFC: display of reference
frequency
FMAX1/2
2 ACTN Current actual speed Only only (positive values only)
Control mode FOR: true actual frequency
Control mode SFC: estimated actual frequency
Open-loop control mode VFC: no display
nN
3 APCUR Current apparent current 2*IN
4 ACCUR Current active current 2*IN
5 ISA0 Voltage or current at
analog input ISA00
10 V / 20 mA
6 ISA1 Voltage at analog input
ISA01
10 V
7 MTEMP Current motor tempera-
ture
Motor temperature only with linear evaluation (PTC)
200 °C
Table 5.14 Settings for 200-FOSA0 analog output
