LX8000 version 0.96 April 2008
Page 15 of 85
4.3.4 Selection control
Selection boxes, also known as combo box on Windows operating system, are used to select
a value from list of predefined values. Use page selector to iterate through list.
4.3.5 Checkbox and checkbox list
Checkbox enables or disables particular parameter. Press SELECT button to toggle value. If
option is enabled a checkmark will be shown, otherwise an empty rectangle will be drawn.
Use page selector to iterate through checkbox list. Press ALL button to enable all options.
4.3.6 Color selector
Colors and fills are set with color selector control. Rotate page selector to change color.
Rotating zoom selector changes color transparency. Transparency is very important for fill
colors, which are used for airspace zones, observation zones and FAI area. If fill color is not
transparent (0%), all other map items will not be seen through it. If fill color is 100% only
the solid border will be drawn.
