Operating elements for driving
3.2 Short description of the operating elements
Operating Manual GMK6300L 3 112 xxx en 3 - 57
xx.xx.xxxx
Steering system warning
ECOS display Main menu
Separate steering crab travel mode on/off
Separate steering for driving around corners on/off
s
–On: Steering system defective – stop immediately,
Display symbol (1) – 5th and 6th axle cannot be steered;
if it is possible, it can only be steered in straight running
position – max. 20 km/h (12 mph)
– Off: No error in the steering system
After engine start;
à p. 4 - 18
While driving;
à p. 5 - 28
– To switch on: Press button once – dot (1) green, maximum 5 km/h
(3 mph)
– Steering wheel steers 1st and 2nd axle lines
– 3rd to 6th axle line steer in the same direction
– To switch off: Press button once – dot (1) black
à p. 5 - 71
– To switch on: Press button once – dot (1) green, maximum 5 km/h
(3 mph)
– Steering wheel steers 1st and 2nd axle lines
– 3rd to 6th axle lines steer for the smallest turning
circle
– To switch off: Press button once – dot (1) black
à p. 5 - 71
