Overview
1.5 Technical data
Operating Manual GMK6300L 3 112 xxx en 1 - 17
xx.xx.xxxx
1.5.6 Superstructure
Engine
Main hoist
Auxiliary hoist
s
Mercedes-Benz: OM 936 LA
Engine emission:
1)
: 97/68/EG Level 4 (TIER 4 Final/Euromot 4)
Power
1)
: 210 kW (282 PS) at 2,200 rpm (ECE R120)
DEF tank: approx. 40 l (10.6 gal)
Fuel tank: 220 l (58 gal)
1)
See also engine data card
Drum diameter: 458 mm (18.03 in) (rope centre to rope centre)
Rope diameter: 22 mm (0.87 in)
Rope length: 350 m (1,148 ft)
Rope pull: 94.4 to 97.7 kN/line (21,220 to 21,960 lbf)
Power unit group: M 3 (to ISO 4301 - 2)
Load spectrum: L1
Factor of the load
spectrum
Km = 0.125
Theoretical service life: D = 3,200 h
Drum diameter: 458 mm (18.03 in) (rope centre to rope centre)
Rope diameter: 22 mm (0.87 in)
Rope length: 350 m (1,148 ft)
Rope pull: 94.4 to 97.7 kN/line (21,220 to 21,960 lbf)
Power unit group: M 3 (to ISO 4301 - 2)
Load spectrum: L1
Factor of the load
spectrum
Km = 0.125
Theoretical service life: D = 3,200 h
