Manitowoc Grove GMK6300L User Manual

Operating elements for crane operation
9.2 Short description of the operating elements
9 - 80 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
9.2.14 Auxiliary hoist
à Auxiliary hoist, p. 11 - 57.
Auxiliary hoist on/off
There is a lamp in the button.
Power units display
Left control lever
Button and lamp for hoist high-speed mode
Short description with main hoist,
à p. 9 - 79
Warning for lifting limit switch shutdown
#
Short description with main hoist
– Press once: – Lamp bright – auxiliary hoist on
– Lamp dim – auxiliary hoist off
à p. 11 - 58
–Green: Auxiliary hoist on
–Red: Auxiliary hoist off
– Back: Lifting
–Forward: Lowering
à p. 11 - 59
