Starting/switching off the engine – for crane operation
10.1 Starting the engine – from the crane cab
Operating Manual GMK6300L 3 112 xxx en 10 - 15
xx.xx.xxxx
10.1.10 Monitoring submenu
The Monitoring submenu shows the most important measured values.
• If necessary, open the main menu ö and press the button (1) once.
This opens the
Monitoring submenu.
The following values are displayed:
The colour of the bar below the values indicates in which area the value can
be found.
1 The hydraulic oil temperature in °C (°F)
2 Fuel supply in percent
3 Voltage in volts
4 The engine speed in rpm
5 The coolant temperature in °C (°F)
6 Carbamide supply in percent
Green: Value OK.
Yellow: Limit value almost reached
Red: Limit value exceeded (or not reached) – warning message;
à p. 11 - 110.
