1.5 Technical data
1 - 10 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
1.5.4 Dimensions and weights of removable parts
This section contains the dimensions and weights of the parts that can be
removed for on-road driving;
à Driving modes, p. 6 - 1.
Spare wheel
Outriggers
Name
Length x width x height
in m (ft)
Weight in kg
(lbs)
Spare wheel 385/95 R 25 1.36 x 1.36 x 0.40
(4.45 x 4.45 x 1.30)
245
(540)
Spare wheel 445/95 R 25 1.50 x 1.50 x 0.45
(4.95 x 4.95 x 1.50)
310
(685)
Spare wheel 525/80 R 25 1.50 x 1.50 x 0.53
(4.92 x 4.92 x 1.74)
355
(785)
Name
Length x width x height
in m (ft)
Weight
in kg (lbs)
Plastic outrigger pad
diameter
0.70 x 0.14
(2.30 x 0.46)13
43
(95)
Steel outrigger pad
diameter
0.70 x 0.14
(2.30 x 0.46)
80
(176)
Front outrigger
1)
,
complete per packet
2.98 x 0.37 x 1.20
(9.78 x 1.21 x 3.94)
1,252
(2,760)
Rear outriggers
1)
,
complete, per packet
2.98 x 0.37 x 1.10
(9.78 x 1.21 x 3.60)
1,365
(3,009)
Rear outrigger, complete,
with outrigger beams, out-
rigger cylinders and out-
rigger pads (ROB)
2)
3.41 x 1.26 x 1.53
(11.19 x 4.13 x 5.02)
5,125
(11,300)
1)
Consists of two complete packets
2)
Additional equipment
