Crane operation
11.4 Settings and displays for crane operation
11 - 108 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
11.4.7 Using the pivoting spotlights
With the relevant equipment, the pivoting spotlights (1) are located on the
main boom. They are controlled from the crane cab.
Switching on
• Press switch (1) down.
Switching off
• Press switch (1) up.
To direct the spotlights forwards
• Press button (2) up.
To direct the spotlights backwards
• Press button (2) down.
The direction of the spotlights will be adjusted
until you let go of the button or they reach
their end position.
If the symbol (1) is displayed then:
• Pivot the spotlights to prevent them from colliding with the boom rest.
G
Risk of accidents due to dazzling during on-road driving!
When driving on the road, always direct the spotlight in such a way that the
reflector points downwards. In this way, you can prevent yourself and other
drivers from being dazzled and causing accidents.
S
Risk of damage to the spotlights!
Check the position of the pivoting spotlights before setting the main boom
down on the boom rest. This prevents the spotlights from colliding with the
boom rest.
