Starting the engine for driving / switching it off
4.1 Starting the engine from the driver's cab
Operating Manual GMK6300L 3 112 xxx en 4 - 5
xx.xx.xxxx
Left side
– When the crane cab door is open, you can
reach the handle (1).
– The handle (3) is located on the outside of
the crane cab.
The handle (2) may only be used for adjusting
the front panel. Do not use the handle as
a climbing aid.
Ladders
You can fold out the ladder (1).
While driving
• Place the ladder (1) in the bracket (2) and
secure it with the spring latch (3).
s
S
Risk of damage to the front control panel!
Do not use the front panel handle as a climbing aid. This way, you avoid
damage due to overloading. Use the handle on the floor of the crane cab
or the exterior handrail.
