Manitowoc Grove GMK6300L - Page 577

Operating elements for crane operation
9.2 Short description of the operating elements
Operating Manual GMK6300L 3 112 xxx en 9 - 113
xx.xx.xxxx
Windscreen
wiper/washing
system
Windscreen wiper on/off
Roof window wiper on/off
Windscreen washing system
Adjusting the wiper stroke interval
In the
Settings submenu
– Off: Push up – wiper goes to end position
– Interval: Middle position
– Continuous
operation:
Push down
– Off: Push up – wiper goes to end position
– Interval: Middle position
– Continuous
operation:
Push down
– Windscreen: Push down
– Skylight: Push up
No additional wiping function is performed
1 Interval display
2 Press once – input mode on
3 Turn – change interval
à p. 11 - 104
