Crane operation
11.3 Crane operation with main boom
Operating Manual GMK6300L 3 112 xxx en 11 - 91
xx.xx.xxxx
Example of telescoping with teleautomation
Assuming the current telescoping is 100/0/0/0/0/0
and the telescoping cylinder is locked in tele-
scopic section I.
The desired telescoping is 50/100/100/100/100/100.
The display should correspond to the opposite
diagram once you have entered the desired
telescope status and confirmed it.
ECOS will calculate the following telescoping
sequence:
Since the first step is retracting, arrow (1) points to the left.
• Move the control lever to retract and hold it.
Telescopic section I is fully retracted. The following processes are carried out
automatically for this.
s
– Telescopic section I retract to 0%
– Telescopic section VI extend to 100%
– Telescopic section V extend to 100%
– Telescopic section IV extend to 100%
– Telescopic section III extend to 100%
– Telescopic section II extend to 100%
– Telescopic section I extend to 50%
