Rigging work
12.6 Outriggers
12 - 44 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
If the symbol (1) appears, this means that the slewing gear is switched on –
the symbols (2) and (3) remain grey.
• Switch off the slewing gear.
Extending/retracting supporting cylinders
• Observe the safety instructions for operating the supporting cylinders;
à p. 12 - 41.
• Press the button below the symbol for the desired movement:
The pre-selected supporting cylinders move until you let go of the respec-
tive button or until the respective end position has been reached.
1 Retract
2 Extend
