Rigging work
12.7 Rigging/unrigging the counterweight
Operating Manual GMK6300L 3 112 xxx en 12 - 59
xx.xx.xxxx
6. If required, assemble the auxiliary hoist; Ã CHECKLIST: Auxiliary
hoist, installing
, p. 6 - 89.
7. Open the
Counterweight submenu; Ã p. 12 - 75.
– Correct the rigging mode, if necessary;
à p. 12 - 76.
– Slew the superstructure into the rigging range and lift counterweight
to the turntable automatically and pretension; Ã p. 12 - 77.
8. Enter the current rigging mode with the newly rigged counterweight
combination on the RCL;
à p. 11 - 23.
9. Only switch on the slewing gear if slewing is permissible for the current
outrigger span;
à Slewing with rigged counterweight, p. 12 - 83.
