Rigging work
12.7 Rigging/unrigging the counterweight
12 - 68 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
Combinations for
the basic equip-
ment in version B
The following counterweight combinations can be combined on the
counterweight platform.
7.0 t (15,432 lbs)
– 7 t base plate
16.5 t (36,376 lbs)
– 7 t base plate
– Two 4.75 t sections
G
Risk of accident due to an incorrect counterweight mass!
Only combine the counterweights in such a manner that the counterweight
mass corresponds to the specifications in this section and in the
Lifting
capacity table
. Other combinations are not permitted.
