Rigging work
12.8 Rigging work on the main boom
Operating Manual GMK6300L 3 112 xxx en 12 - 113
xx.xx.xxxx
Switching the air traffic control light on and off:
Removing You must remove the rod with the anemometer/air traffic control light
before driving on the road;
à p. 12 - 112.
• Switch off the air traffic control light – press the switch (1) upwards and
inwards.
• Remove the plug and close the sockets (4)
and (5) with the protective caps.
• Wind the cables on to the holder (2).
• Remove the rod (1) from the holder (3).
• For transportation, fasten the retaining pins
to the rod (1).
• If necessary, store the rod in the storage
compartment (1).
To switch on: Press in switch (1) at the bottom
To switch off: Press in switch (1) at the top
