14.3 Fuses
14 - 10 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
Designation Amperage (A) Function
F4/1 10 Engine electronic system (ADM)
F4/2 10
24 V/12 V voltage transformer
Crane cab lighting
Air traffic control light
Radio
F4/3 3
Engine electronic system diagnostics
plug
Camera on the turntable
1)
auxiliary
hoist
1)
F4/4 25 Air-conditioning system
1)
F4/5 – Unassigned
F4/6 15 Auxiliary heater
1)
F4/7 – Unassigned
F4/8 20 CraneSTAR system
Designation Amperage (A) Function
F5/1 15 Spotlight
F5/2 15
Spotlight
Status display RCL
F5/3 15
Windscreen wiper/washing system,
Cigarette lighter
F5/4 10
Fan
1)
Camera on the turntable
1)
auxiliary
hoist
1)
F5/5 5 Instrument panel lighting
F5/6 5
Voltage monitoring
Engine electronic system diagnostics
plug
F5/7 10 Heater fan
F5/8 10
Battery heating
1)
Auxiliary heater
1)
1)
Additional equipment
