Medrad™ Intego™ PET Infusion System
52
d. Insert the Needle Cartridge into the holder so the RP Tube exits the cartridge away
from the holder.
e. Stow the needles safely in the Vial Compartment until ready to install the Multi-Dose
Vial by lowering the Needle Insertion Device cover, rotating the Needle Insertion
Device clockwise until it stops, then pushing down on the Needle Insertion Device
until it is back in its original position.
6. Insert RP Tube in the RP Pump:
a. Open the RP Pump door.
b. Insert the RP Tube into the RP Pump as shown in the left panel below. For proper
installation, the tubing collar must rest immediately outside the RP Pump on the side
closest to the Vial Shield Compartment.
c. Close the RP Pump door.
CAUTION: Incorrect installation of the SAS may result in improper functioning
of the Intego™ PET Infusion System.
7. Insert the Confluence into the SAS Confluence Holder.
