Functional Principle, Technical Data
capaNCDT 6200
2.2.2 Sensor Cable
Sensor and controller are connected by a special, double screened sensor cable.
Do not shorten or lengthen these special cables.
Usually, a damaged cable can not be repaired.
Switch off the device when plugging and removing connectors.
Do not crush the sensor cable.
Do not modify to the sensor cable.
> Lost of functionality
Model Cable length Cable ø 2 axial
connector
1x axial
+ 1x 90
0
For sensors Min. bending radius
once permanently
CCgxC 2/4 or 6 m 3.1 mm • 0.05 - 0.8 mm
10 mm 22 mm
CCgxC/90 2/4 or 6 m 3.1 mm • 0.05 - 0.8 mm
CCgxB 2/4 or 6 m 3.1 mm • 1 ... 10 mm
CCgxB/90 2/4 or 6 m 3.1 mm • 1 ... 10 mm
CCmxC 1.4/2.8 or 4.2 m 2.1 mm • 0.05 - 0.8 mm
7 mm 15 mm
CCmxC/90 1.4/2.8 or 4.2 m 2.1 mm • 0.05 - 0.8 mm
CCmxB 1.4/2.8 or 4.2 m 2.1 mm • 1 ... 10 mm
CCmxB/90 1.4/2.8 or 4.2 m 2.1 mm • 1 ... 10 mm
The sensors of type CSH have integrated a 1.4 long sensor cable. Cable lengths of 2.8 m are available too if
required.
Other cable lengths are also available on request.
The sensor model CSE1 (measuring range 1 mm) has the connector type C.
