Page 81
Ethernet Interface
capaNCDT 6200
6.7.1.2 Filter type / Averaging
Filter type
No Averaging
Moving average Value
Filter width 2 / 3 /
4 / 5 / 6 / 7 / 8
Designation of averaging type. Av-
eraging number indicates, about
how many current measuring
values should be averaged in the
controller, before a new measur-
ing value is output.
Arithmetic mean Value
Median Value
Dynamic noise rejection
It is recommended, to use averaging for statical measuring or slowly changing measuring values.
An averaging reduces noise or suppresses distortions in measuring values.
6.7.1.3 Analog Low Pass Filter
Filter active / inactive Switches the deep pass filter with 20 Hz limit frequency on analog output
6.7.2 Trigger Mode
Menu Settings > Measurement settings > Trigger
This menu item determines the trigger behavior. The triggering is released by an external electrical signal, see
4.7.2 or by the command $ GMD, see 6.4.3.
If the trigger mode is turned off, the capaNCDT 6200 will send the measuring values without interruption and
with the adjusted data rate.
Trigger
Rising edge A measuring value is output per edge.
Level high Level triggering. Measuring value output, as long as the level is active.
Rising edge (gate) Starts resp. stops the measuring value output alternatively.
No trigger Controller sends measuring values continuously.
Grey shaded
fields require a
selection.
Value
Dark-bordered
fields require
you to specifie
a value.
