MICRO-EPSILON CS02 - Version (VER); Set Mathematic Function (SMF)

Page 66
Ethernet Interface
capaNCDT 6200
6.4.11 Version (VER)
Requesting the current software version including date.
VER
Command $VER<CR>
Response $VERDT6200;V1.2a;8010079<CRLF>
6.4.12 Set Mathematic Function (SMF)
Sets a math function on a certain channel.
SMF
Command $SMFm:Offset,Factor1,Factor2,Factor3,Factor4<CR>
Response $SMFm:Offset,Factor1,Factor2,Factor3,Factor4,OK<CRLF>
Index m: 1…4
(Channel number)
If a channel is selected, which is already
reserved by electronics, the result of the math
function is now transmitted instead of the mea-
sured value.
Offset 24 bit offset value with prefix in hex format,
at which 21 bit comply with 100 % measured
value.
Numbers exceeding 21 bit are therefore
greater (for example +3FFFF = complies with
200 % of the measured value).
Factor1, ..., Factor4 Multiplication factors (including prefix), with
which the measured values of channel 1 up
to 8 are multiplied. The range of values of -9.9
up to +9.9 with a decimal place. Structure of
factors: Prefix and a one-digit number with a
decimal place, example +3.4
