Page 84
Ethernet Interface
capaNCDT 6200
6.8.5 Import, Export
Menu Settings > System settings > Manage settings
Here you can export all controller settings in a file or reimport them from a file.
The Export feature generates a text file which you can either store
or display with an editor.
Sensor
settings
e. g. Measuring range, linearization settings
Controller
settings
e. g. Measurement settings, math function,
system settings (e. g. language)
Ethernet
settings
e. g. Address type (static, DHCP), IP address,
operating mode after start
When importing settings, consider if you want to replace the cur-
rent controller and/or Ethernet settings.
Choose the desired import option in the settings section.
6.9 Firmware Update
The controller has a firmware update function. We recommend to always use the latest firmware version. You
can find the latest firmware version on our website and it can be installed with the attached Firmware Update
Tool.
