Page 17
Functional Principle, Technical Data
capaNCDT 6200
2.3 Technical Data
Controller type DT62x0 with DL6220 DT62x0 with DL6230
Resolution static 0.004 % FSO 0.0005 % FSO
Resolution dynamic 0.02 % FSO (5 kHz) 0.005 % FSO (5 kHz)
Bandwidth 5 kHz (-3dB) 5 kHz (-3dB)
Bandwidth adjustable to 20 Hz to 20 Hz
Data rate output digital max. 3.906 kSa/s max. 3.906 kSa/s
Linearity (typical) ≤ ±0,05 % d.M. ≤ ±0,025 % d.M.
Max. sensitivity deviation ≤ ±0.1 % FSO ≤ ±0.1 % FSO
Long term stability ≤ 0.02 % FSO / month ≤ 0.02 % FSO / month
Synchronous operation supported
(multiple control units)
DT6230 only DT6230 only
Isolator measurement no no
Temperature stability 200 ppm 200 ppm
Temperature range
operation
sensor
1
-50 ... +200 °C (-58 ... +392 °F) -50 ... +200 °C (-58 ... +392 °F)
controller +10 … +60 °C (+50 ... +140 °F) +10 … +60 °C (+50 ... +140 °F)
storage -10 … +75 °C (+14 ... +167 °F) -10 … +75 °C (+14 ... +167 °F)
Supply
DT6220: 24 VDC (12 … 36 VDC)
24 VDC (15 … 36 VDC)
DT6230: 24 VDC (15 ... 36 V)
Power consumption at 24 VDC
DT6220 3.1 W (typical)
DT6230 3.8 W (typical)
per DL6220 1.8 W (typical); 2.0 W (max.)
per DL6230 1.9 W (typical); 2.2 W (max.)
Output
0 … 10 V (short-circuit proof) 0 … 10 V (short-circuit proof)
4 … 20 mA (load max. 500 Ohm) 4 … 20 mA (load max. 500 Ohm)
Ethernet Ethernet
1) A operation temperature of -50 ... +100 °C (-58 to +212 °F) applies for the sensors CSG0.50-CA and CSG1.00-CA -50
