Ethernet Interface
capaNCDT 6200
6.4.17 Query Data Port (GDP)
Queries the port number of the data port.
Command $GDP<CR>
Response
$GDP<Port number>OK<CRLF>
Example: $GDP10001OK<CRLF>
6.4.18 Set Data Port (SDP)
Sets the port number of the data port. Range: 1024 ...65535.
Command $SDP<Portnumber><CR> Example: $SDP10001OK<CR>
Response $SDP<Portnumber>OK<CRLF>
6.4.19 Access Channel Information (CHI)
Reads channel-specific information (e.g. serial number of the display board).
Command $CHlm<CR>
Response $CHlm:ANO...,NAM...,SNO...,OFS...,RNG...,UNT...,DTY...OK<CRLF>
Index
m (Channel number): 1 - 4
ANO = Article number
NAM = Name
SNO = Serial number
OFS = Measuring range offset
RNG = Measuring range
UNT = Unit of measuring range (e.g. µm)
DTY = Data type of measuring value (1 = measuring value as INT,
0 = no measuring value)
