Installation and Assembly

capaNCDT 6200

4.4 Controller

4.4.1 Basic Unit, Demodulator Module

34 (1.34)

25 (.98)

125 (4.92)

90 (3.54)

DT 6220

DL 6220

Fig. 7 Dimensional drawing controller

Dimensions in mm (inches), not to scale
