MICRO-EPSILON CS02 User Manual

Page 33
Installation and Assembly
capaNCDT 6200
ø9.4 (.37)
Cable length x
17.5 (.69)
13.7 (.54)
8.6 (.34)
ø5.4 (.21)
37 (1.46)
ø7 (.28)
ø6 (.24)
ø2.1
27 (1.06)
Sensor cable CCmxC
Sensor cable CCmxC/90
ø3.1
(.12)
21 (.83)
ø6 (.24)
ø5.4 (21)
8 (.31)
13.1 (.52)
16.9 (.67)
Cable length x
ø2.1
(.08)
27 (1.06)
37 (1.46)
ø7 (.28)
ø9.4 (37)
Sensor cable CCmxB
Dimensions in mm (inches), not to scale
ø8.9
(.35)/SW7
25 (.98)
20.5 (.81)
30.5 (1.20)
ø10
(.39)
ø7 (.28)
Sensor cable CCmxB/90
Model Cable length Cable ø 2 axial
connector
1x axial +
1x 90
0
For sensors Min. bending radius
CCmxC 1.4/2.8 or 4.2 m 2.1 mm • 0.05 - 0.8 mm
7 mm
(once)
15 mm
(permanently)
CCmxC/90 1.4/2.8 or 4.2 m 2.1 mm • 0.05 - 0.8 mm
CCmxB 1.4/2.8 or 4.2 m 2.1 mm • 1 ... 10 mm
CCmxB/90 1.4/2.8 or 4.2 m 2.1 mm • 1 ... 10 mm
