Page 68
Ethernet Interface
capaNCDT 6200
6.4.13 Get Mathematic Function (GMF)
Reads out the math function of a channel.
GMF
Command $GMFm<CR>
Response $GMFm:Offset,Factor1,Factor2,Factor3,Factor4OK<CRLF>
Index m: 1…4
(Channel number)
If a channel is selected, which is already reserved
by electronics, the result of the math function is now
transmitted instead of the measured value.
Offset 24 bit offset value with prefix in hex format, at which
21 bit comply with 100 % measured value.
Numbers exceeding 21 bit are therefore greater (for
example +3FFFF = complies with 200 % of the mea-
sured value).
Factor1, ..., Factor4 Multiplication factors (including prefix), with which the
measured values of channel 1 up to 4 are multiplied.
The range of values of -9.9 up to +9.9 with a decimal
place. Structure of factors: Prefix and a one-digit num-
ber with a decimal place. Example +3.4.
6.4.14 Clear Mathematic Function (CMF)
Deletes the math function on a channel.
CMF
Command $CMFm<CR>
Response $CMFmOK<CRLF>
Index m: 1…4 (Channel number)
