MICRO-EPSILON CS02 User Manual

Page 23
Installation and Assembly
capaNCDT 6200
4.2.4 Dimensional Drawings Sensors
Cylindric sensors
CS02
12
(.472)
ø6f7 (.236 dia.)
12
(.472)
CS005
ø6f7 (.236 dia.)
ø3 (0.118 dia.)
ø8f7 (.314 dia.)
CS05
12
(.472)
11 (.433)
CSE05
12 (.47)
ø6f7
(.24 dia.)
ø5.7 (.22)
15 (.59)
ø10h7
(.394 dia.)
CS08
9 (.35)
M=1:2
ø20h7 (.79 dia.)
24
-0.2
(.945)
-0.008
CS2
CS1
CSE1
12 (0.47)
ø8f7 (0.31 dia.)
ø10h7 (.394 dia)
ø10h7 (.394 dia.)
CS1HP
20
-0.2
(.787
-0.008
)
CSE2
ø14h7 (0.55 dia.)
18.5 (0.73)
22 (0.87)
21
-0.2
(o.83
-0.008)
ø7.7 (0.30 dia.)
9 (0.35)
ø13.7 (0.54 dia.)
Connector side
Dimensions in mm
(inches)
Circumferential clamp-
ing possible from 3 mm
behind the front face.
Dimensional drawings
of other sensors are
available on request.
