Installation and Assembly
capaNCDT 6200
ø30h7 (1.18 dia.)
ø20h7 (.79 dia.)
24
-0.2
(.945)
-0.008
CS3
M=1:2
ø20h7 (.79 dia.)
ø40h7 (1.58 dia.)
CS5
M=1:2
ø20h7 (.79 dia.)
ø60h7 (2.36 dia.)
M=1:2
CS10
16.5
(.649)
16.5
(.649)
24
-0.2
(.945)
-0.008
24
-0.2
(0.94
-0.008
)
16.5
(0.65)
Connector side
Dimensions in mm
(inches)
Circumferential clamp-
ing possible from 3 mm
behind the front face.
Dimensional drawings
of other sensors are
available on request.
