Installation and Assembly
capaNCDT 6200
4.4.2 Housing Cover
8 (.31)
90 (3.54)
125 (4.92)
5
(.20)
8
(.31)
5
(.20)
8
(.31)
4 (.16)
M4
50 (1.97)
2x M4
Mounting hole M4 for
wall fastening respectively
mounting on DIN-rail
Fig. 8 Dimensional drawing housing cover
Dimensions in mm (inches), not to scale
The controller is mounted using mounting plates or holding clamps for a mounting on DIN-rail which are
included with the conversion kit supplied, see A 1.1.
