MICRO-EPSILON CS02 User Manual

Page 18
Functional Principle, Technical Data
capaNCDT 6200
Controller type DT62x0 with DL6220 DT62x0 with DL6230
Sensors all sensors suitable all sensors suitable
Sensor cable standard CCm1.4x; CCg2.0x CCm1.4x; CCg2.0x
Sensor cable (matched)
≤ 6 m (with CCgxx) ≤ 4.2 m (with
CCmxx)
≤ 6 m (with CCgxx) ≤ 4.2 m (with
CCmxx)
Trigger TTL, 5 V
FSO = Full Scale Output
2.4 Options
Article number Designation Description
Suitable for articles
2303018
DL6220
2303022
DL6220/ECL2
2303023
DL6220/ECL3
2303029
DL6220/LC
2982044
LC DL62x0
digital
Special calibration of linearity on digital
output
○ ○ ○
•
2982045
LC DL62x0
analog
Special calibration on linearity on analog
output
○ ○ ○
•
2982046 ECL2 DL6220
Special tuning for 2 times sensor cable
length
- • - •
2982047 ECL3 DL6220
Special tuning for 3 times sensor cable
length
- - • •
2982048 EMR2 DL6220 Extended measuring range (factor: 2)
○ ○ ○
•
2982049 RMR1/2 DL6220 Shortened measuring range (factor: 1/2)
○ ○ ○
•
