MICRO-EPSILON CS02 User Manual

Page 96
Appendix| Tilt Angle Influence on the Capacitive Sensor
capaNCDT 6200
A 3 Tilt Angle Influence on the Capacitive Sensor
θ
Sensor
CS02
CS1
CS10
0 0.1 0.2 0.3 0.4 0,5 0.6 0.7 0.8 0.9 1
Angle  [°]
Measurement error [‰ MR]
0
-1
-2
-3
-4
-5
-6
-7
-8
-9
-10
Target
CS02
CS1
CS10
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Angle  [°]
Measurement error [‰ MR]
0
-1
-2
-3
-4
-5
-6
-7
-8
-9
-10
θ
Sensor
Target
Fig. 30 Example of measuring range deviation in the
case of a sensor distance of 10 % of the measuring
range
Fig. 31 Example of measuring range deviation in the
case of a sensor distance of 50 % of the measuring
range
CS02
CS1
CS10
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Angle  [°]
Measurement error [‰ MR]
0
-1
-2
-3
-4
-5
-6
-7
-8
-9
-10
θ
Sensor
Target
i
Figures give an influence example shown on
the sensors CS02/CS1 and CS10 in the case
of different sensor distances to the target. As
this results from internal simulations and cal-
culations, please request for detailed informa-
tion.
Fig. 32 Example of measuring range deviation in the
case of a sensor distance of 100 % of the measur-
ing range
