Ethernet Interface
capaNCDT 6200
6.2 Data Format of Measuring Values
All measuring values, recorded at a time, are combined into a measuring value frame (One measuring value
per channel).
Several measuring value frames are combined to a measuring value block and then transmitted together with
a header as a TCP packet.
All measuring values and the header are transmitted in little-endian format.
Contents Size Description
Preamble 32 bit
„MEAS“ as an ASCII text
Order number 32 bit
Order number of sensor as int
Serial number 32 bit
Serial number of sensor as int
Channels
(Bit field)
64 bit
Bit field, which channel available. Two bits per channel are used: „00“=
Channel is not available; „01“=channel available. The lowest channel is on
the most low-order bit ->Thereby determining the number of channels N
possible.
Status 32 bit Is not used.
Frame number M /
bytes per frame
16 bit /
16 bit
One frame = one measuring value per channel
Measuring value
counter
32 bit
Measuring value counter (of 1st frame)
Measuring value
frame 1 [number
channels N]
N *
32 bit
Measuring values all channels, starting with the lowest channel number
Measuring value
frame 2 [number
channels N]
N *
32 bit
„
.... ...
...
Measuring value
frame M [number
channels N]
N *
32 bit
„
