MICRO-EPSILON CS02 User Manual

Page 32
Installation and Assembly
capaNCDT 6200
Sensor cable CCgxC
ø9.4 (.35)
Cable length x
17.5
(.69)
13.7 (.54)
8.6 (.34)
ø6 (.24)
ø5.4 (.21)
ø3.1
36.5 (1.44)
26.5 (1.04)
ø7 (.28)
Sensor cable CCgxC/90
ø3.1 (.12)
21 (.83)
ø6 (.24)
ø5.4 (.21)
8 (.31)
13.1
(.52)
16.9 (.67)
Sensor cable CCgxB
Cable length x
ø3.1
(.12)
26.5 (1.04)
36.5 (1.44)
ø7 (.28)
ø9.4 (.37)
Dimensions in mm (inches), not to scale
Sensor cable CCgxB/90
ø8.9
(.35)/SW7
25 (.98)
20.5 (.81)
30.5 (1.20)
ø7(.28)
ø10 (.39)
Model Cable length Cable ø 2 axial
connector
1x axial +
1x 90
0
For sensors Min. bending radius
CCgxC 2/4 or 6 m 3.1 mm • 0.05 - 0.8 mm
10 mm
(once)
22 mm
(permanently)
CCxgC/90 2/4 or 6 m 3.1 mm • 0.05 - 0.8 mm
CCgxB 2/4 or 6 m 3.1 mm • 1 ... 10 mm
CCgxB/90 2/4 or 6 m 3.1 mm • 1 ... 10 mm
