Page 90
Appendix| Accessories, Service
capaNCDT 6200
Mounting plate Aluminum /
powder-coated
Plugging off assistance for con-
nector
15
(.95)
50 (1.97)
20
(.79)
10
(.39)
3
(.12)
0.7
(.03)
8
(.31)
2
(.08)
R5
R2
135 °
Dimensions in mm (inches), not to scale
Further more, the conversion kit contains sleeve nuts, threaded rods in different lengths and screws.
