96 Microtek ScanWizard Pro TX for Mac & PC
RGB/CMYK list
box arrow
CMYK/RGB expansion
arrow
Click DEL button to
delete a selected
color
RGB/CMYK Profiles as
defined in the CMS setup
3. To use CMYK or RGB values as “From” and “To” Selective colors, click on the
expansion arrow provided in the Selective Color dialog box.
Either CMYK or RGB color and edit boxes will then display (see figure above). To
change the display mode, click on the list box arrow and select the alternate
color type from the list box.
NOTE
: :
: :
: The list box will list the same CMYK and RGB color profiles as defined in the
Color Matching Setup dialog box under the Preferences menu of the Preview window.
Then proceed to set the From and To settings as they are done under the LCH
mode. Note that as you manipulate colors in CMYK/RGB mode, changes on the
color settings will be reflected in the LCH From and To edit boxes.
